Functions:

  • Pressure pumping
  • Injectivity Testing
  • Fluid pumping for coil tubing including mixing chemicals on the fly
  • Acid pumping
  • Displace frac balls & hold annulus pressure simultaneously
  • Pressure testing including wellheads and BOP testing

Specifications:

  • True twin totally independent power & hydraulic systems
  • Two QSK 15 Cummins engines rated at 600 HP each
  • Two 6000 series Allison automatic transmissions
  • Two Eaton two speed gearboxes for greater rate control
  • Two Gardener Denver boost pumps
  • Two Gardener Denver GD-600 compact pumps outfitted with 3” plungers
  • 15,000psi capable
  • Rate 1000L/min on each pump @ 0Mpa @ 2000L/min combined
  • Rate 750L/min on each pump @ 24Mpa @ 1500L/min combined
  • Rate 500L/min on each pump @ 35Mpa @ 1000L/min combined
  • Two 2m3 batch tanks with paddles for mixing
  • 60 meters of certified 1502 2’’ treating iron
  • Climate controlled operators cabin
  • Fully equipped crew change trucks for 24 hour operations

Data Acquisition System:

  • Full data acquisition system with the capability to print graphs email directly from site
  • Pump rate
  • Pump pressure
  • Total volume pumped
  • Inlet & discharge temperature
  • Inlet & discharge pressure
  • Engine temperature
  • Engine RPM
  • Engine oil pressure & temperature
  • Hydraulic oil pressure & temperature
