Functions:

  • Heating Water in Tanks/Pits/Ponds
  • Heating Water in C-rings
  • Slip Stream Heating

Skid Specifications:

  • 25’ x 8’ Engineered Skid
  • ” A106 grade B coil feed Off of 4” header manifold c/w Thermo-finned tubing
  • 4” manifold system Off of rear skid c/w blow down air lines
  • 10” Inlet & Outlet Lines With 10” Bypass line (Globe Valve/Slipstream Valve)
  • Compressor (DV 5HP)
  • 230V 30AMP Twist Lock w/150’ plug in Cable
  • Work Lights Mounted Around Unit
  • 30lb Propane Tank Mounted

Burner Specifications:

  • Electronic Temperature Burner Control System Input & Output
  • Constant Burner Control Monitoring System
  • 40,000,000 BTU Input
  • LPG Plumbing/NG Plumbing
  • High Temperature shut down on burner system
  • Nitrogen Emergency Shutdown System
  • Safety Emergency Flow Switches

Control Panel Specifications:

  • Control Panel Profire (PF 3100 Interface BMS Module)
  • Dual Ion Pilot Assembly (Ignitors)
  • UV Integrated Flame Scanner
  • Type K Temperature Control Modules
  • ” Flowmeter Hoffer Model
